Product profile

1.1 General description

This is a type of mirror aluminum PCB for the application of Led Lighting. It's a single

layer MCPCB board at 1.2 mm thick with 1 W/MK thermal conductivity. The aluminum

plate is from ITEQ, Solder mask and silkscreen from Taiyo. It's fabricated per IPC 6012

Class 2 using supplied Gerber data. 25 panels are packed for shipment.

1.2 Features and benifits

A. Optimization combination of power circuit and control circuit,
B. Replace the fragile ceramic substrate and obtain a better mechanical durability,
C. Effective heat diffusion in the design of the circuit,
D. Reduce the operating temperature of the equipment,
E. Improve the power density and reliability of the device,
F. Prolong the service life of the product,
G. Right manufacturing instruction (MI),
H. Products and Manufacturing are certified by authorized organizations.
I. 100% tests inclusive of electrical test and AOI inspection.
J. Customer complaint rate: <1%
K. No MOQ, low cost for prototypes and samples.
L. 1-10 pieces are offered for sale.

1.3 Application

Automotive lighting, Constant voltage control, Light conversion system, Shopping mall

lighting

1.4 Parameter and data sheet

The Variety of Aluminum PCBs
