Rogers 4003C High Frequency PCB with 8mil, 12mil, 20mil, 32mil and 60mil Coating with Immersion Gold, Silver, tin and OSP

Hello Everyone,

Today, we’re going to introduce high frequency PCB built on RO4003C laminates.

RO4003C is a woven glass cloth reinforced hydrocarbon resin ceramic-filled laminate from Rogers Corporation, which has very similar electrical properties to PTFE and its processability is similar to epoxy resin (glass cloth) material.

Now let’s see the 5 advantages of RO4003C laminates.

1. Superior high frequency performance

RO4003C materials are hydrocarbon ceramic filled laminates, not PTFE which are designed to offer superior high frequency performance.

2. Low dielectric loss

Low loss results in excellent electrical performance and allows applications with high operating frequencies.

3. Stable electrical properties versus frequency

RO4003C material possesses the properties of RF microwave circuits, matching networks and controlled impedance transmission lines.

4. Low thermal coefficient of dielectric constant

This allows the RO4003C to exhibit excellent dimensional stability, a property needed for mixed dielectric multi-layer PCBs constructions and reliable plated through holes.

5. Cost

RO4003C laminates can be fabricated using standard FR-4 processes, do not require speicalized via preparation prcoesses, can be processed by automated handling systems and scrubbing equipment used for copper surface preparation. This properties allow it can be using in volume manufacturing and get competitively priced.

PCB Capability

Double sided circuit boards on RO4003C are available in a variety of thicknesses, such as 12mil, 16mil, 20mil, 32mil and 60mil. It's used in a variety of typical and non-traditional microwave / radio frequency applications, such as base station antennas, power amplifiers, RFID, radar and sensors etc.

The basic colour of RO4003C PCB is white.

Multilayer PCB

Multilayer circuit boards are built on different cores of RO4003C. For example, a 4-layer PCB on 2 cores of 32mil RO4003C, a 4-layer board on 12mil core and 20mil core of RO4003C etc. The core has fixed thickness which is very important to the electrical length of RF lines on the circuit board.

Hybrid PCB

In order to save production cost but not reduce signal loss in high frequency environment, mixed pressure production with FR-4 came into being. At present, the technology of mixed circuit board is mature and popular in the market.

We specialize in provide you with prototype, small batches and mass production service.

If you have any requirements on this kind of PCB, please feel free to contact us.

Thank you for your reading.

Bicheng PCB is headquartered in Shenzhen, a city with great economic vitality. Based in China, we adhere to the philosophy of servicing small and medium sized companies offering variety of circuit boards to meet the demands of market.

We maintain the highest standards which support products that exhibit exceptional quality, performance and reliability. The circuit board ranges from conventional FR-4 to PTFE, metal core to flexible circuits which are used in the industries of home appliances, portable and consumable electronics, medical filed, aerospace as well as telecommunications etc.
