    Dual Layer PCB On 30 mil RO4350B With Immersion ROHS Compliant

    Brief Introduction
    RO4350B High Frequency Circuit Material is glass reinforced hydrocarbon/ceramic laminates (Not PTFE) designed for performance sensitive, high volume commercial applications. Currently double sided and multilayer RO4350B PCB’s are available at Bicheng company. Double sided RO4350B PCB with thickness 10mil (0.254mm), 20mil (0.508mm), 30mil (0.762mm) and 60mil (1.524mm) are the bestsellers. We provide prototype runs, small batches and volume production services.
    Advantages
    1) Excellent high frequency performance due to low dielectric tolerance and loss;
    2) Excellent dimensional stability.
    3) Low thermal coefficient of dielectric constant;
    4) Low Z-Axis expansion;
    5) Low in-plane expansion coefficient;
    6) Stable electrical properties verus frequency;
    Applications
    1) Attenuator, Automatic gate induction;
    2) LNB's for direct broadcast satellites;
    3) Microstrip antenna, spread spectrum;
    4) Microstrip and cellular base station antennas and power amplifiers;
    5) RF identifications tags
    6) Spread spectrum communications systems
    7) Trunk amplifier, splitter module etc.
    PCB Case: Dual Layer PCB On 30 mil RO4350B With Immersion ROHS Compliant
    (Printed circuit boards are custom-made products, the picture and parameters shown are just for reference)
    General description
    This is a type of double sided PCB built on high frequency substrate with Tg 288°C for the application of WiFi attenuator. It's 0.8 mm thick, white silkscreen over green solder mask. All via's are open to air. Pads are covered by immersion gold. The base material is used from Rogers RO4350B, entire board supplying 1 PCB up. They're fabricated per IPC 6012 Class 2 using supplied Gerber data. Each 25 panels are packed for shipment.
    Features and benefits
    RO4350B exhibits a stable dielectric constant over a broad frequency range. This makes it an ideal substrate for broadband applications;
    Tg > 280 ℃;
    Stable electrical properties verus frequency;
    Low thermal coefficient of dielectric constant;
    Low Z-Axis expansion;
    High solderability, no stressing of circuit boards and less contamination of PCB surface;
    SMT process is resistant to reflow soldering, resistant to rework;
    30000 square meter month capability;
    Application
    GPS antenna, directional coupler, spread spectrum, Tower Mounted Amplifier
    Parameter and data sheet
    PCB SIZE65 x 32mm=1PCS
    BOARD TYPEDouble sided PCB
    Number of Layers2 layers
    Surface Mount ComponentsYES
    Through Hole ComponentsYES
    LAYER STACKUPcopper ------- 35um(1 oz)+plate TOP layer
    RO4350B 0.762mm
    copper ------- 35um(1oz) + plate BOT Layer
    TECHNOLOGY
    Minimum Trace and Space:5.5 mil / 5 mil
    Minimum / Maximum Holes:0.3 mm / 5.2 mm
    Number of Different Holes:9
    Number of Drill Holes:102
    Number of Milled Slots:0
    Number of Internal Cutouts:0
    Impedance Control:no
    Number of Gold finger:0
    BOARD MATERIAL
    Glass Epoxy:RO4350B Tg280℃, er<3.48, Rogers Corp.
    Final foil external:1.5 oz
    Final foil internal:N/A
    Final height of PCB:0.8 mm ±10%
    PLATING AND COATING
    Surface FinishImmersion Gold
    Solder Mask Apply To:TOP, 12micron Minimum
    Solder Mask Color:Green, PSR-2000GT600D, Taiyo Supplied.
    Solder Mask Type:LPSM
    CONTOUR/CUTTINGRouting
    MARKING
    Side of Component LegendTOP
    Colour of Component LegendWhite, IJR-4000 MW300, Taiyo brand
    Manufacturer Name or Logo:Marked on the board in a conductor and leged FREE AREA
    VIAPlated through hole(PTH), minimum size 0.3mm. Solder mask uncovered
    FLAMIBILITY RATINGUL 94-V0 Approval MIN.
    DIMENSION TOLERANCE
    Outline dimension:0.0059"
    Board plating:0.0029"
    Drill tolerance:0.002"
    TEST100% Electrical Test prior shipment
    TYPE OF ARTWORK TO BE SUPPLIEDemail file, Gerber RS-274-X, PCBDOC etc
    SERVICE AREAWorldwide, Globally.
