Brief Introduction
Just as its name implies, high frequency is that the frequency is
relatively high, generally refers to the frequency of >=300 MHz
(i.e. wave length <=1m), that is, the usual radio frequency
band. The electromagnetic wave of frequency >=1GHz is called
microwave.
Typical frequencies for wireless applications:
* Current mobile: 0.9GHz - 2GHz
* 3G systems: 2.5GHz
* Bluetooth: 2.5GHz
* GPS: 12.6GHz
* LMDS: 24GHz and 40GHz
* Automotive: 77GHz
Market: RFID, Wireless communications, base station and antenna,
amplifier, military products, consumer electronics.
High frequency printed circuit board or microwave PCB refers to the
printed circuit board made on the high frequency (microwave)
substrate copper clad plate. The common types are: Double-sided
board, multilayer board and mixed structure.
Mixed structure includes high performance special substrate, PP
sheet + ordinary performance board and PP sheet mixed pressing
board; high frequency substrate + ordinary FR4 substrate; high
frequency substrate + metal base etc.
PCB Case: High Frequency PCB Bare Board | 10 mil RO4350B Printed
Circuit Board | Immersion Gold HF PWB
(Printed circuit boards are custom-made products, the picture and
parameters shown are just for reference)
General description
This is a type of double sided PCB built on 10mil RO4350B substrate
with Tg 280°C for the application of 4G Coverage. It's 0.3mm thick
finished with white silkscreen over green solder mask and immersion
gold are plated on pads. The base material is used from Rogers
Corp., entire board supplying 2 up per panel. They're fabricated
per IPC 6012 Class 2 using supplied Gerber data. Each 50 panels are
packed for shipment.
Features and benefits
Reducing signal loss in high frequency application meets the
development needs of communication technology;
Excellent high frequency performance due to low dielectric
tolerance and loss;
Excellent surface planarity, helpful for PCBs with BGA packages to
reduce failure rate during assembly and soldering;
Excellent surface planarity for CSP mounted components to reduce
failure rate during assembly and soldering;
Engineering design prevents problems from occurring in
pre-production;
ISO9001, ISO14001, UL certified manufacturing factory;
Quick Lead time: 3-5 days;
Small quantity order is accepted;
Application
Modular oscilloscope, optical coupler, Indoor wall hanging antenna,
RF transceiver
Parameter and data sheet
| PCB SIZE | 30 x 20mm=2PCS |
| BOARD TYPE | Double sided PCB |
| Number of Layers | 2 layers |
| Surface Mount Components | YES |
| Through Hole Components | YES |
| LAYER STACKUP | copper ------- 18um(0.5 oz)+plate TOP layer |
| RO4350B 0.254mm |
| copper ------- 18um(0.5oz) + plate BOT Layer |
| TECHNOLOGY | |
| Minimum Trace and Space: | 5 mil / 4 mil |
| Minimum / Maximum Holes: | 0.2 mm / 0.2mm |
| Number of Different Holes: | 1 |
| Number of Drill Holes: | 15 |
| Number of Milled Slots: | 0 |
| Number of Internal Cutouts: | 0 |
| Impedance Control: | no |
| Number of Gold finger: | 0 |
| BOARD MATERIAL | |
| Glass Epoxy: | RO4350B Tg280℃, er<3.48, Rogers Corp. |
| Final foil external: | 1.0 oz |
| Final foil internal: | N/A |
| Final height of PCB: | 0.3 mm ±0.1 |
| PLATING AND COATING | |
| Surface Finish | Immersion gold |
| Solder Mask Apply To: | TOP 12micron Minimum |
| Solder Mask Color: | Green, PSR-2000GT600D, Taiyo Supplied. |
| Solder Mask Type: | LPSM |
| CONTOUR/CUTTING | Routing |
| MARKING | |
| Side of Component Legend | TOP |
| Colour of Component Legend | White, IJR-4000 MW300, Taiyo brand |
| Manufacturer Name or Logo: | Marked on the board in a conductor and leged FREE AREA |
| VIA | Plated through hole(PTH), minimum size 0.22mm. Via tented. |
| FLAMIBILITY RATING | UL 94-V0 Approval MIN. |
| DIMENSION TOLERANCE | |
| Outline dimension: | 0.0059" |
| Board plating: | 0.0029" |
| Drill tolerance: | 0.002" |
| TEST | 100% Electrical Test prior shipment |
| TYPE OF ARTWORK TO BE SUPPLIED | email file, Gerber RS-274-X, PCBDOC etc |
| SERVICE AREA | Worldwide, Globally. |
