Introducing the Next Generation of High-Frequency Performance:
Rogers RO4830 High-Frequency Laminates
Experience the future of high-frequency circuit board technologies
with the cutting-edge Rogers RO4830 high-frequency laminates. These
innovative laminates are designed to elevate the performance of
high-frequency applications while offering cost-effective solutions
for a wide range of industries.
Unleashing Superior Technical Specifications:
Rogers RO4830 laminates boast a dielectric constant of 3.24 at
77GHz/23°C and a dissipation factor of just 0.0033 at 10GHz/23°C,
ensuring exceptional signal integrity and efficiency. With an
excellent thermal coefficient of dielectric constant at -30 ppm/°C,
these laminates provide stability and reliability in varying
thermal conditions.
Reliability Redefined:
Built for longevity, the RO4830 laminates are significantly
resistant to oxidation, maintaining consistent performance over
time. The UL 94 V-0 flame retardant rating enhances safety
measures, making them ideal for applications demanding high
reliability.
Efficiency at its Core:
The laminates feature LoPro reverse treated copper foil for smooth
cladding, contributing to an insertion loss of just 2.2 dB per inch
at 77 GHz. This optimized filler, resin, and glass composite system
ensures top-notch performance, making them a preferred choice for
demanding high-frequency applications.
Q: What sets the RO4830 laminates apart from traditional materials?
A: The RO4830 laminates offer a dielectric constant of 3.24 at
77GHz/23°C and a low dissipation factor of 0.0033 at 10GHz/23°C,
providing superior signal integrity and efficiency compared to
conventional materials.
Seamless Integration in Automotive Radar Sensors:
Ideal for 76-81 GHz automotive radar sensor PCB applications, the
RO4830 laminates offer a cost-effective solution without
compromising on quality. Their compatibility with standard FR-4
processes allows for seamless integration, making them a versatile
choice for a variety of applications.
Crafted for Precision and Durability:
The 2-layer rigid PCB construction, coupled with a finished board
thickness of 0.4mm, ensures durability and reliability. With
immersion silver surface finish and stringent quality control
measures, the RO4830 laminates are crafted to meet the highest
industry standards.
Elevate Your High-Frequency Designs:
Whether you are designing cutting-edge automotive radar sensors or
high-performance RF components, the Rogers RO4830 high-frequency
laminates offer unmatched performance and reliability. Join the
future of high-frequency circuit board technologies and elevate
your designs to new heights with Rogers RO4830 laminates.
